EBOX - BLUETOOTH ADAPTER FOR SOLAR CONTROL

eBox-Bluetooth Adapter

Adapter which can make certain compatible solar controllers and inverters function via Bluetooth communication for wireless monitoring, and parameter settings with a mobile phone APP.

Features

Realize wireless monitoring function of solar controller and inverter

Support mobile phone APP, plug and play, simple and convenient to set

Use high performance, ultra-low power consumption Bluetooth dedicated chip

Adopt Bluetooth 4.0 and BLE technology

Fast communication, strong anti-interference ability

No need of external power supply

Communication distance up to 10m

Master reset adapter

Technical Specifications

Input voltage eBox-BLE-01: 5VDC (Direct powered by RS485 port)

Standby power consumption: 0.04W

Operation power consumption: 0.05W

Communication distance: 10m

Port baud rate 300bps~230400bps (Default115200)

Communication: RS485 to BLE

Interface type: RJ45

Connecting cable: Standard network cable (Parallel cable)

Overall dimension: 51 x 67 x 24.5mm

Mounting dimension: 41.2mm

Mounting hole size: 3.2mm

Working temperature:  -20~70
